1622	Profi	Bormax®, Forstner Bit

Art.- No.	O-Ø [mm]	Stem Ø [mm]	SØ [mm]	OAL [mm]	Effective L. [mm]		€
1622.008	8	6,5	8	90	57	Accessory	25.85
1622.009	9	7,5	8	90	57	Accessory	25.85
1622.010	10	8	8	90	57	Accessory	25.85
1622.011	11	8	8	90	57	Accessory	25.85
1622.012	12	8	8	90	57	Accessory	25.85
1622.013	13	8	8	90	57	Accessory	26.65
1622.014	14	8	8	90	57	Accessory	26.70
1622.015	15	8	8	90	57	Accessory	26.10
1622.016	16	8	8	90	57	Accessory	26.10
1622.017	17	8	8	90	57	Accessory	28.35
1622.018	18	8	8	90	57	Accessory	28.35
1622.019	19	8	8	90	57	Accessory	34.05
1622.020	20	8	8	90	57	Accessory	28.35
1622.021	21	8	8	90	57	Accessory	34.05
1622.022	22	10	10	90	57	Accessory	30.70
1622.023	23	10	10	90	57	Accessory	31.65
1622.024	24	10	10	90	57	Accessory	31.65
1622.025	25	10	10	90	57	Accessory	32.80
1622.026	26	10	10	90	57	Accessory	32.80
1622.027	27	10	10	90	57	Accessory	42.20
1622.028	28	12	10	90	57	Accessory	37.90
1622.029	29	12	10	90	57	Accessory	45.90
1622.030	30	12	10	90	57	Accessory	37.90
1622.031	31	12	10	90	57		41.65
1622.032	32	12	10	90	57	Accessory	37.90
1622.033	33	12	10	90	57	Accessory	53.35
1622.034	34	12	10	90	57	Accessory	45.90
1622.035	35	12	10	90	57	Accessory	45.90
1622.036	36	14	10	90	57	Accessory	53.40
1622.037	37	14	10	90	57	Accessory	56.41
1622.038	38	14	10	90	57	Accessory	53.40
1622.040	40	14	10	90	57	Accessory	53.40
1622.042	42	16	10	90	57	Accessory	69.90
1622.043	43	16	10	90	57	Accessory	69.90
1622.044	44	16	10	90	57	Accessory	69.90
1622.045	45	16	10	90	57	Accessory	69.90
1622.046	46	16	13	90	57	Accessory	77.50
1622.048	48	16	13	90	57	Accessory	77.50
1622.049	49	16	13	90	57	Accessory	113.60
1622.050	50	16	13	90	57	Accessory	77.50
1622.054	54	18	13	90	57	Accessory	124.90
1622.055	55	20	13	90	57	Accessory	113.60
1622.058	58	20	13	90	57	Accessory	116.50
1622.060	60	20	13	90	57	Accessory	117.30

Sets

Art.- No.	Description		€
1622.505	5 pcs. Set in wooden case Ø 15, 20, 25, 30, 35 mm	Accessory	153.50
1622.606	6 pcs. Set in wooden case Ø 15, 20, 25, 30, 35, 40 mm	Accessory	201.45
1622.570	7 pcs. Set in wooden case Ø 15, 20, 25, 30, 35, 40, 50 mm	Accessory	271.10
1622.508	8 pcs. Set in wooden case Ø 15, 20, 25, 30, 35, 40, 45, 50 mm	Accessory	333.85
1622.515	15 pcs. Set in wooden case Ø 10, 12, 15, 16, 18, 20, 22, 25, 26, 28, 30, 35, 40, 45, 50 mm	Accessory	519.85
1622.504	4 pcs. Set in wooden case Ø 35, 40, 45, 50 mm	Accessory	221.80
1622.530	3 pcs. Set in wooden case Ø 40, 50, 60 mm	Accessory	223.20
1622.555	5 pcs. Set in wooden case Ø 20, 25, 30, 35, 40 mm	Accessory	179.15
1622.556	5 pcs. Set in wooden case Ø 22, 25, 38, 42 mm incl. Extension 250 mm for Spice grinders	Accessory	197.15
1622.805	5-pcs. set in metal tin Ø 15, 20, 25, 30, 35, mm	Accessory	153.70
1622.522	22 pcs. Set in wooden case Ø 10 - 50 mm		741.65

Bormax®! Centre point with cutting character. Two in reverse order staggered, grooved main cutting edges (from Ø 11 mm) and one circumferential cutting edge with longitudinal grooves - both effecting that a clear less feed force is necessary. Also they minimizes the friction and the growth of heat. Hexagonal shank for a better power transfer. Rapid drilling in soft wood, European hard wood, chipboard, MDF etc. Top for freehand drilling and stationary use. The low heat development offers an incredibly long service life with highest drilling quality. In combination with extension shanks of product line 1639 perfectly suitable for drilling deep holes.

Technical changes or mistakes reserved! All prices are non-binding price recommendations excluding VAT. Items marked with (*) are discontinued items.
